Resulting in some small discontinuities between adjacent movements. In an easing may be much smaller than the increment/decrement before, Since the values are computed in a fixed 20 ms raster, the last degree increment or decrement

Bouncing of the SINE function results in the upper (positive) half of the sine.Īll easing types (starting in flavor IN_OUT, then IN, OUT and BOUNCE) in one plot. Bouncing: Start with OUT, then return with IN to start degree.InOut: Start the function with 0 go to 1 and back to 0.Except for PRECISION, where we do a bounce if approaching from below (go out from origin). Out: Start the function with 1 and go to 0 linear.Except for PRECISION, where we do a bounce if approaching from above (go in to origin). In: Start the function with 0 and go to 1 linear.Dummy is used for delays in callback handler.Īll easing functions can be used in the following variants:Īll ease functions are called internally with the value: PercentageOfCompletion / 100 giving a call value from 0 to 1.This enables it to taken out the slack/backlash of any hardware moved by the servo. So the target position is always approached from below. Precision is like linear, but if descending, add a 5 degree negative bounce in the last 20 % of the movement time.

Easy implementation of a move list - see ConsecutiveEasingsWithCallback example.

All ServoEasing objects are accessible by using the ServoEasing::ServoEasingArray.

Multiple servo handling by *ForAllServos() functions like setIntegerDegreeForAllServos(3, 135, 135, 135).

Servo speed can be specified in degree per second or milliseconds for the complete move.

Allow to specify an arbitrary mapping between degrees and microseconds by attach(int aPin, int aMicrosecondsForServoLowDegree, int aMicrosecondsForServoHighDegree, int aServoLowDegree, int aServoHighDegree).

Trim and reverse are applied after constraint processing.

Constraints for minimum and maximum servo degree can be specified.

Reverse operation of servo is possible e.g.

Its value is internally added to each requested position.

A trim value can be set for any servo.

User-specified callback function at "servo arrived" enables movement control independent of main loop.

Float angels are supported to allow fine-grained servo control comparable to using microseconds.

Degree values >= 400 is taken as microsecond values for the servo pulse to allow fine-grained control.

This functions are not available for all platforms.

Non blocking movements are implemented by the startEaseTo* functions by using a timer.

All servos can move synchronized or independently.

Linear and 9 other ease movements are provided.

Arduino servo project how to#

The LightweightServo library uses the internal Timer1 with no software overhead and therefore has no problems with servo twitching or interrupt blocking libraries like SoftwareSerial, Adafruit_NeoPixel and DmxSimple.įor instructions how to enable these alternatives, see Compile options / macros.

If you require only one or two servos, you may want to use the included LightweightServo library (only for AVR), instead of the Arduino Servo library.

Arduino servo project install#

The expander in turn requires the Arduino Wire library or a compatible one and is bound to their restrictions.įor ESP32 you need to install the Arduino ESP32Servo library. ServoEasing works with the Arduino Servo library as well as with PCA9685 servo expanders. generated by an joystick or other "slow" changing inputs and therefore does not change suddenly or does not jump, you most likely do not need this library!, you may consider to use a digital low pass or simple EMA filters to smooth your values used to control the servos. Its purpose is to interpolate the movement between two servo positions set by software. Requests for modifications / extensions.Timer usage for interrupt based movement.Handling multiple servos with the internal ServoEasingArray.Using the included Lightweight Servo library for ATmega328.Using PCA9685 16-Channel Servo Expander.Compile options / macros for this library.Comparison between Quadratic, Cubic and Sine easings.It uses the standard Arduino Servo library and therefore has its restrictions regarding pins and platform support.Īvailable as Arduino library "ServoEasing".
